ADVANCED LOCK ELECTROMAGNETIC LOCK OP-LM
SISSL
Specifications:
- Size (LxWxH): 250x48.8x27.9(mm) / 9.84" x 1.92" x 1.10"
- Armature Plate Dimension (LxWxH): 180x38.8x13(mm) / 7.09" x 1.53" x 0.51"
- Holding Force: 280kg / 600Lbs
- Input Voltage: 12 or 24VDC
- Current Draw: 12V/520mA or 24V/260mA
- LED: Red shows locked; Green shows unlocked
- Signal Output: Lock signal (NO/NC/COM)
- Suitable: Wooden door, Glass door, Metal door, Fireproof door
- Surface Temp: Less than +20? / 68?
- Operating Temp: -10?~+55?(14?-131?)
- Humidity: 0~90%(non-condensing)
- Cover Finish: Anodized aluminum
- Lock Finish: Zinc
- Armature Plate Finish: Zinc
- Thickness of door leaf: 50mm
- Product: Weight: 1.95KG / 4.3lb
Package:
- 1 x Electric Magnetic Lock
- 1 x Armature Plate
- 1 x User manual
- 1 x Installation Kit
12VDC Input:
- Connect the positive (+) lead from a 12VDC power source to V+; Connect the ground (-) lead from a 12DDC power source to V-; Check jumper for 12VDC operation.
24VDC Input:
- Connect the positive (+) lead from a 24VDC power source to V+; Connect the ground (-) lead from a 24DDC power source to V-; Check jumper for 24VDC operation.
Note:
- "I" Bracket designed for the door frame is too thick.
- "L" bracket for outward door when the header is narrow.
- "ZL" bracket for inward door application.
- "U" Bracket specially designed for glass door solution.
