Cooling Capacity

5,275 W / 18,000 Btu/h.

Capacity Rate (Min)

3,250 Btu/h.

Capacity Rate (Max)

19,910 Btu/h.

Power Input (Cooling/Heating)

1,690 W

Running Current ( Cooling/Heating)

7.6 A

EER

3.12 W/W 10.65 Btu/h.W

Power Supply

1 / 220-240V / 50Hz (Ø / V / Hz)

Air Flow Rate(Indoor,Max)

18.5 (653) m2/min

Air Flow Rate(Outdoor,Max)

42 (1483) ?/min

Moisture Removal

1.04 l/h.

Sound Level(Indoor,H/M/L/SL)

42 / 37 / 35 / 29  dB(A)+3

Sound Level(Outdoor,Max)

51/ 53 dB(A)+3

Refrigerant (Type)

R-410A

Refrigerant (Charge (at 7.5 m))

1,150 g

Additional Refrigerant Charge

20 g/m

Circuit Breaker*

25 A

Power Supply Cable

3*1.5 No.*mm2

Power and Transmission Cable

4*1.5 No.*mm2

Piping Connections(Liquid Side)

 6.35 mm

Piping Connections(Gas Side)

12.7 mm

Drain Hose (O.D / I.D * length)

21.5 / 16.0 (0.85 / 0.63) * 350 mm(in) * mm

Piping Length (Standard / Max)

7.5 (24.6) / 20 (66.6) m(ft)

Max. Elevation Difference

7 (23.0) m(ft)

Fan(Indoor) Type

Cross Flow Fan

Fan(Outdoor) Type

Fan,Propeller

Operation Range (Cooling Indoor)

16 ~ 32 (60.8 ~ 89.6) oC (oF)

Operation Range (Cooling Outdoor)

18 ~ 48 (64.4 ~ 118.4) oC (oF)

Dimensions(Indoor (W*H*D))

998*330*210 mm

Dimensions(Outdoor (W*H*D))

870*660*360 mm

Net Weight(Indoor)

 11.6 (25.57) kg

Indoor(Tool Code)

SK

Indoor(Remote)

(Common) 2 Way + Gen mode

Indoor(Remote Controller Type)

Wireless LCD (AKB74955619)

Indoor(Grille Front Look)

Sirius-E (White)

Indoor(Display)

88 Seq

Outdoor(Tool Code)

UE

Outdoor(Panel Type)

Steel

Outdoor(Condenser Type)

CU

Pre-Filter (in Front Grille)Anti bacteria air filter (Stallion Pre filter)

Yes

* Vane Horizontal

Normal

Temperature Control

Thermistor

Auto Clean

Yes

Natural Wind

Yes

Fan Speed (SH/H/MH/M/ML/L/SL)

7

Airflow Direction Control(up & Down)

Auto

Airflow Direction Control(left & right)

Manual

Setting Temperature Range(Cooling)

16-30

Temperature Increment

1 (°C)

Auto Operation (Micom Control)

Yes

Self Diagnosis

Yes

Timer

24hr On/Off

Sleep Operation

Yes

Soft Dry Operation

Yes

Restart Delay(minute)

3

Display Light (On/Off)

Yes

Energy Saving

Yes

Jet Cool

Yes

Indirect Air

Yes
